Resetting the system

The last break time is set to 00:00 and the driver's attention level is set to 5 (very attentive) when the driver resets the Driver Attention Warning system.
The driver attention warning system resets in the following situations.
- The engine is turned OFF.
- The driver unfastens the seat belt and then opens the driver’s door when stopped.
- The driver takes a break from driving that lasts more than 10 minutes.
The driver attention warning system will operate again when the driver restarts driving.

System disabled

The Driver Attention Warning system enters the ready status and displays the 'Disabled' screen in the following situations.

- The camera sensor is unable to detect the lanes.
- Driving speed remains under 64 km/h (40 mph) or over 177 km/h (110 mph).

System setting and activation

System setting The Driver Attention Warning system is set to be the Normal position when your vehicle is first delivered to you from the factory. To turn ON the Driver Attention Warn ...

System malfunction

When the “Check System” warning message appears, the system is not working properly. In this situation, take your vehicle to an authorized Kia dealer and have the system checked. WARNIN ...
