Kia Forte: Features of your vehicle / Manual climate control system
![](images/manual_climate_control_system-151/1/forte_104.png)
■ Type A
![](images/manual_climate_control_system-151/1/forte_171.png)
■ Type B
1. Fan speed control knob
2. Temperature control knob
3. Air conditioning button (if equipped)
4. Rear window defroster button
5. Air intake control button
6. Mode selection knob
✽ NOTICE
Operating the blower when the
ignition switch is in the ON position
could cause the battery to discharge.
Operate the blower when
the engine is running.
CAUTION - Conductors
To prevent damage to the conductors
bonded to the inside
surface of the rear window,
never use sharp instruments or
window cleaners containing
abrasives to clean the wi ...
1. Start the engine.
2. Set the mode to the desired position.
For improving the effectiveness of
heating and cooling;
- Heating:
- Cooling:
3. Set the temperature control to the
desired po ...
